A vapor barrier is a polyethylene sheeting system installed on the ground and walls of a crawl space or basement to block ground moisture from migrating into the structural environment above. Understanding what a proper vapor barrier consists of, however, goes well beyond simply laying plastic on the floor.
The thickness of vapor barrier sheeting, measured in mils, is one of the most significant specification decisions a homeowner or contractor makes. A 20-mil reinforced vapor barrier significantly reduces vapor diffusion and resists punctures from gravel, debris, and service personnel working in the crawl space.
Using staples or tape without the appropriate adhesive backing results in seams that separate within one to three years, allowing ground moisture to migrate freely through the gaps in the barrier. A perfectly spec'd 20-mil liner installed with poorly treated seams performs no better than a budget barrier at preventing moisture migration.
Covering only the floor and stopping the barrier at the wall-floor junction leaves the porous block or concrete foundation walls as an open pathway for moisture to enter the crawl space environment. The combination of floor coverage, properly lapped and taped seams, and full wall coverage to the sill plate creates a complete moisture envelope that dramatically reduces crawl space humidity and protects the wood framing above.
The downstream benefits of a properly installed vapor barrier extend well beyond simply keeping the crawl space dry. If the barrier is incomplete or poorly sealed, a dehumidifier simply works harder against an unlimited moisture supply, running continuously and consuming excessive energy without achieving target humidity levels.
Our installers are trained on manufacturer specifications for every product we use.
The materials we install in Lewisville are built to last decades, not years.
Full perimeter coverage is non-negotiable in our installation standard.
Our vapor barrier installations carry a written warranty covering materials and workmanship.
The result is a continuous moisture envelope that protects your floor framing from ground vapor for years to come.
We remove deteriorated existing barriers, prepare the substrate, and install a properly spec'd replacement that meets current installation standards.
We install vapor barrier systems under flooring or as a standalone moisture management layer in unfinished basements.
Drainage board integration is recommended for Lewisville basements that experience both seasonal dampness and occasional liquid intrusion.
Adding a properly sized dehumidifier completes the moisture management system and ensures consistent relative humidity control regardless of outdoor conditions.
Inspection findings are documented with photos and a written report detailing any deficiencies and recommended corrective actions.
We measure the space, assess existing moisture conditions, document any existing barrier or mold, and identify all penetrations that will need to be addressed in the installation
Based on site conditions, we specify the appropriate mil rating, calculate material quantities, and plan the seaming layout for maximum coverage and minimum waste
Sheeting is laid, overlapped at 12 inches minimum, taped with butyl tape at all seams, and extended up all walls with mechanical fastening at the top edge
We walk through the completed installation with you, confirm all seams and coverages are complete, and provide written warranty documentation before leaving
"We had a previous vapor barrier installation that was barely 6-mil and had separated seams throughout. The humidity in our crawl space was unacceptable and we were starting to see mold on the floor joists. JCB Waterproofing and Construction came in, took out the failing old barrier, and installed a proper system that actually works. The difference in our indoor air quality was noticeable within a week."
"Very professional team that explained the difference between the grades of vapor barrier sheeting before recommending anything. The material quality and seaming were both done to a very high standard. We can already see the humidity meter reading dropping consistently."
"The crew extended the barrier all the way up the walls to the sill plate, which the contractor who did our original installation did not do. The proper wall-to-sill installation finally completed our moisture protection. Great work from a team that clearly knows what they are doing."
Do not let ground moisture continue to damage your floor framing and indoor air quality
